S6 2-in-1 Video Controller
Multi-screen display Fully digital signal processing Send as a single unit
The S6 Multi-Screen Video Splicing & Transmission All-in-One Machine is a professional-grade LED display control device, featuring robust video signal reception, splicing, and processing capabilities. It can drive LED large screens with up to 3.9 million pixel points and supports three HDMI and one DVI digital signals, enabling seamless switching between multiple inputs. Additionally, it allows for flexible screen configurations, supporting up to 8 images displayed simultaneously.
The S6 features 6-channel Gigabit Ethernet outputs and comes equipped with a range of robust, practical functions, offering flexible screen control and high-quality image display—making it perfectly suited for use with LED displays of all specifications.
Panel Introduction
Main features:
- Supports preview rendering—what you see is what you get;
- Supports a wide range of signal interfaces, including HDMI 1.3 × 3 and DVI × 1;
- Control interfaces: RJ45 × 1, RS232 × 1;
- Maximum input resolution: 7680×1080@30Hz, with resolution fully customizable.
- Maximum load capacity of 3.9 million pixels, with a single network port supporting resolutions up to 1920 pixels wide and 1920 pixels high.
- Supports seamless switching between video sources, and allows input images to be stitched or scaled according to the display resolution.
- Supports 8-picture display with freely adjustable position and size;
- The network port output supports analog audio, which can be decoded via a multi-function card.
- Supports ultra-high-definition 4K@30Hz video signal processing;
- Supports handheld terminal control (app);
- Supports hot backup of input sources;
- Supports brightness adjustment for LED displays;
- Supports irregular-shaped splicing and free routing, breaking traditional rules;
- Supports RS232 and TCP/IP central control protocol;
- Supports fault detection for convenient medical reference;
- Supports input signal EDID management;
- Supports simultaneous software and hardware operation;
- Supports the entire series of Vislink receiver cards;
S6 2-in-1 Video Controller
Multi-screen display Fully digital signal processing Send as a single unit
The S6 Multi-Screen Video Splicing & Transmission All-in-One Machine is a professional-grade LED display control device, featuring robust video signal reception, splicing, and processing capabilities. It can drive LED large screens with up to 3.9 million pixel points and supports three HDMI and one DVI digital signals, enabling seamless switching between multiple inputs. Additionally, it allows for flexible screen configurations, supporting up to 8 images displayed simultaneously.
The S6 features 6-channel Gigabit Ethernet outputs and comes equipped with a range of robust, practical functions, offering flexible screen control and high-quality image display—making it perfectly suited for use with LED displays of all specifications.
Panel Introduction
Main features:
- Supports preview rendering—what you see is what you get;
- Supports a wide range of signal interfaces, including HDMI 1.3 × 3 and DVI × 1;
- Control interfaces: RJ45 × 1, RS232 × 1;
- Maximum input resolution: 7680×1080@30Hz, with resolution fully customizable.
- Maximum load capacity of 3.9 million pixels, with a single network port supporting resolutions up to 1920 pixels wide and 1920 pixels high.
- Supports seamless switching between video sources, and allows input images to be stitched or scaled according to the display resolution.
- Supports 8-picture display with freely adjustable position and size;
- The network port output supports analog audio, which can be decoded via a multi-function card.
- Supports ultra-high-definition 4K@30Hz video signal processing;
- Supports handheld terminal control (app);
- Supports hot backup of input sources;
- Supports brightness adjustment for LED displays;
- Supports irregular-shaped splicing and free routing, breaking traditional rules;
- Supports RS232 and TCP/IP central control protocol;
- Supports fault detection for convenient medical reference;
- Supports input signal EDID management;
- Supports simultaneous software and hardware operation;
- Supports the entire series of Vislink receiver cards;
